Design
Pressure |
Full Vaccum/ 6.0 Kg/cm2 |
Design
Temperature |
-100C
to 1800C (Standard Cobalt Blue Glass) -100C
to 2400C (High Temperature Ultra Glass) |
|
Tolerances |
As per DIN
2873 |
Flange
Dimension |
As per ANSI
B 16.5 150#, 300# or DIN 2501 part- I PN-10/16/25 |
|
Glasslining |
As per DIN
28136 |
External
Coating |
Epoxy base
primer followed by PU finish |
|
Lining
Thickness |
1.0 to 2.2
mm |
For C.S Spark Test For Cast
Iron |
Internal
Inspection : 20,000 V (only once) Final
Inspection : 10,000 V |
|
Internal
Inspection : 10,000 V (only once) Final
Inspection : 5000 V |
